LR21 SeriesLandscape Rakes
- Strong 4x4 steel frame
- iMatchTM compatible
- Steel tines and waffle plates
- Adjustable tine beam
Features
Expand All
Collapse All
Tubular steel for maximum support
Hitch makes hook-up time quick and easy
Steel tines and waffle plates
Adjustable tine beam
Strong 4x4 steel frame supports angled tine beam
Tubular steel for maximum support
A strong 4x4 steel frame supports an angled tine beam for superior performance.
Compatible with Category 1 and iMatch™ hitches
Hitch makes hook-up time quick and easy
The Frontier™ Medium-Duty Landscape Rake is 3-point hitch compatible with Category 1 and iMatch hitches, which ensures quick, efficient hookup.
Steel tines and waffle plates enhance durability
Steel tines and waffle plates
Heat-treated steel tines are mounted with bolts and held secure with a steel waffle plate on the Frontier™ LR21 Series Medium-Duty Landscape Rake.
This mounting ensures positive spacing and alignment, while providing increased strength and durability. These waffle plates also make replacement fast and easy, saving time and money.
Adjustable tine beam allows multiple raking positions
Adjustable tine beam
The tine beam on the Frontier™ LR21 Series Medium-Duty Landscaping Rake can be adjusted to five different forward raking positions and three reverse raking positions, allowing the operator to choose the desired raking profile.
Specs & Compare
Add Model
| Specs & Compare | ||||
|---|---|---|---|---|
| Select up to 4 models to compare specifications | John Deere LR21 Series Landscape Rakes |
Dimensions
| Working width | 182.9 cm 72 in. |
|---|
Weight
| Operating | 138.3 kg 305 lb |
|||
|---|---|---|---|---|
| Shipping | 181.4 kg 400 lb |
Tractor compatibility
| PTO horsepower | 8.9-29.8 kW 12-40 hp |
|---|
Hitch
| Compatibility | Cat. 1 | |||
|---|---|---|---|---|
| iMatch™ compatible (Cat.1) |
Tines
| Quantity | 36 | |||
|---|---|---|---|---|
| Dimensions | 0.8x2.5 cm 0.3125x1 in. |
|||
| Spacing | 2.5 cm 1 in. |
Raking angle
| Positions | 5 Forward, 3 reverse | |||
|---|---|---|---|---|
| Degrees | 0, 15, 30 degree (angle) |
Pivot
| Degrees | 360 degree (angle) |
|---|
Parking stands
| Standard | Yes |
|---|
Duty
| Type | Medium |
|---|
Shipping
| Configuration |
|---|
Set-up time
| Labor hours |
|---|
Warranty
| Time period | 1 year |
|---|
Additional information
| Date collected |
|---|
-
