344 P-TierCompact Wheel Loader
- Net Power: 76 kW (103 hp) at 2,000 rpm
- Operating Weight: 8860 kg (19,533 lb.)
- Bucket Capacity: 1.5–2.0 m3 (2.0–2.6 cu. yd.)
STARTING AT:
$206,300.00USD1
Optional accessories and attachments shown. See your dealer for available models, options, attachments and pricing. Product options and accessories may not be available in all regions.
Specs & Compare
Add Model
| Specs & Compare | ||||
|---|---|---|---|---|
| Select up to 4 models to compare specifications | John Deere 344 P-Tier Compact Wheel Loader |
DRIVELINE
| Engine Manufacturer | John Deere | |||
|---|---|---|---|---|
| Engine Model | PowerTech PWS 4045H | |||
| Displacement, ltr (Inches³) | 4.5 (275) | |||
| Rated Speed, rpm | 2000 | |||
| Engine Output - Net, kW (hp) | 76 (103) | |||
| Torque, Nm (lbf / ft) | 405 (299) | |||
| Transmission Type | Hydrostatic | |||
| Front Differential Type | Locking | |||
| Rear Differential Type | Open | |||
| Tire size - Standard | 17.5 R25 | |||
| Service Brake - Type | Wet Disc & Drum | |||
| Service Brake - Actuation | Hydraulic | |||
| Parking Brake - Type | Wet Disc |
DIMENSIONS
| Height - Over Cab, mm (ft/in) | 3030 (9 ft 11 in) | |||
|---|---|---|---|---|
| Wheelbase, mm (ft/in) | 2600 (8 ft 6 in) | |||
| Ground clearance, mm (inches) | 430 (16.9) | |||
| Width Over tires - Std, mm (ft/in) | 2370 (7 ft 9 in) | |||
| Height - Pivot Pin, mm (ft/in) | 3720 (12 ft 2 in) | |||
| Reach - At 2130mm 45° Dump, mm (ft/in) | 1640 (5 ft 5 in) |
CAPACITIES
| Fuel Tank, ltr (gallons (US)) | 155 (40.9) | |||
|---|---|---|---|---|
| Hydraulic Tank, ltr (gallons (US)) | 115 (30.4) | |||
| Heaped Capacity, m³ (yd³) | 1.5 (2) | |||
| Breakout - Bucket, kgf (lbf) | 7443.9 (16411) | |||
| Ride Control System | Yes | |||
| Pump Type | Gear | |||
| Pump Flow - 1, lt/min (gallons (US) / min) | 115 (30) | |||
| System Pressure, bar (PSI) | 240 (3480) |
WEIGHTS
| Operating Weight, kg (lbs) | 8860 (19533) |
|---|
