195.6 cm (77 in.) of underframe clearance
Perform detasseling in tall varieties of seed corn with 195.6 cm (77in.) of underframe clearance on the Hagie™ 204SP Detasseler.
Hagie is a trademark of Hagie Manufacturing Company and similar to John Deere branded equipment, John Deere will also support Hagie equipment.
167.6-cm (66-in.) lift arm on Hagie™ 204SP Detasseler
Experience a wide range of detasseling heights with a 167.6-cm (66-in.) lift arm range. The lift arm feature provides adjustments with the upper and lower position for detasseling capability that ranges from 0.63 m up to 2.5 m (2 ft up to 8.4 ft) above ground.
(B) Lift arm range of 167.6 cm (66 in.)
Hagie is a trademark of Hagie Manufacturing Company and similar to John Deere branded equipment, John Deere will also support Hagie equipment.
6965.8-kg (15,357-lb) weight based on 12-row-6 lift machine with cutters
Timing is critical when it comes to detasseling. The 6965.8-kg (15,357-lb) Hagie™ 204SP Detasseler features a lightweight design, allowing you to enter the field any day to perform your detasseling needs.
Hagie is a trademark of Hagie Manufacturing Company and similar to John Deere branded equipment, John Deere will also support Hagie equipment.
Air-ride suspension and air bag linkage
Electric air compressor for active air
The Hagie™ 204SP Detasseler features active air suspension.
Maximize operator comfort and improve operational functions of the detasseler attachments with the active air suspension on the Hagie 204SP Detasseler. In the field or on the road, active air suspension makes for a remarkably smooth ride.
An electric air compressor and air bag linkage enhances the air-ride suspension by making sure there is always the right amount of air in the suspension bags, from roading to operating in different field conditions.
Hagie is a trademark of Hagie Manufacturing Company, LLC and similar to John Deere branded equipment, John Deere will also support Hagie equipment.
QuickTach system allows easy changeover from cutter to quad puller attachments with simply pulling two locking pins
QuickTach system allows easy changeover from cutter to quad puller attachments with simply pulling two locking pins
No tools are needed to quickly change from cutting to pulling attachments with just two locking pins on each head.
Cutter attachment
Puller attachment
G5 Universal Display and AutoTrac Universal 300 in a Hagie 204SP cab
RowSense feeler on a Hagie 204SP
John Deere AutoTrac RowSense gives the Hagie 204SP detasseler the ability to steer itself. The result? Reduce operator fatigue and the ability to relax and focus more on the quality of detasseling job the machine is doing. With the G5 Universal Display, StarFire™ 7500 antenna, AutoTrac Universal 300, and RowSense feelers, the Hagie 204SP Detasseler is ready to AutoTrac through the field in the long hours of detasseling season.
Detasseler cab exterior
Detasseler cab interior
The Hagie detasseler comes with a cab that offers a comfortable and quiet working environment with plenty of visibility, space, and features. For those long hours required during the detasseling season, the John Deere cab new to the Hagie 204SP provides improved operator comfort to reduce fatigue in the field. The cab features a Hagie designed side console that still provides simple detasseling controls.
Cab features
Hagie 204SP operator station
Operators can easily adjust features and controls in the 204SP Detasseler operator’s station to maximize comfort and keep the machine performing throughout the field.
Bluetooth is a trademark of Bluetooth SIG, Inc.
Montag cover crop system
Montag cover crop system
Boost the versatility of the Hagie 204SP Detasseler and optimize soil health with a cover crop seeding solution. The Montag 2108 Cover Crop System is an engineered solution specifically designed to be compatible with model year 2015 to 2024 Hagie 204SP Detasselers.
Hagie is a trademark of Hagie Manufacturing Company and similar to John Deere branded equipment, John Deere will also support Hagie equipment.
Montag single bin cover crop system
The Montag cover crop system features the Gen 2 2108 single bin design totaling 1-m3 (35-cu ft) capacity, sized to fit the operation. The system is controlled with Montag MTC200 controller for a simple, user-friendly operator interface.
Montag chart
Montag chart
When performing seeding applications at 16.1 km/h (10 mph), producers can apply 2.3 kg (5 lb) to 40.8 kg (90 lb) of seed per acre to meet individual productivity needs (see the rate charts above for more details). The Montag 2108 Cover Crop System provides a unique solution to protect and nurture soil health while enhancing versatility, making the Hagie 204SP Detasseler a one-machine solution for late season needs.
| Key specifications | |
| Row configurable | 12 (9.1 m [30 ft]) to 15 (11.43 m [37.5ft]) |
| Section sonfigurable | 1-4 sections |
| Slide gate control | Manual lever |
| Controller | Montag MTC200 controller |
| Product capacity (bin) | 0.85 m3 (30-cu ft) bin: 0.99 m3 (34.8-cu ft), 1.11 ton* (2447.13 lb) |
| Rate capacity (bin) | See 2108 rate chart at www.montagmfg.com |
| 2108 weight** | 385.55 kg (850 lb) to 453.6 kg (1,000 lb) |
| Fill height | 3.6 m (12 ft) |
| Product fill inlet size | 0.97 m (3.2 ft) |
| Product outlet hose size | 5.08 cm (2 in.) |
| Required hydraulic capacity | 52.99 L/min (14 gpm) |
| Required hydraulic pressure | 137.89 bar (2000 psi) |
*Calculated using 1.025 kg/L (64 lb/cu ft) product density
**Unloaded, dry weight (approximated). Excludes platform and mounting kit
NOTE: Montag Manufacturing has an allied partnership agreement with John Deere as it relates to the cover crop system and is responsible for providing sales and technical support to dealers.
For additional information about the system, visit www.montagmfg.com or call 712-852-4572. Montag is a trademark of Montag Manufacturing, Inc.
| Specifications | ||||
|---|---|---|---|---|
| John Deere 204SP Hagie™ Self-Propelled Detasseler¹ |
| Engine | Peak rated power 129 kW 173 hp |
|||
|---|---|---|---|---|
| Detasseling speed range | Low range: 0 to 16.1 km/h 0 to 10 mph High range: 0 to 20.9 km/h 0 to 13 mph |
|||
| Transport speed, maximum | 20.9 km/h 13 mph |
|||
| Suspension | Independent air-ride | |||
| Crop clearance with standard tires | 195.6 cm 77 in. |
| Peak rated power | 129 kW 173 hp |
|||
|---|---|---|---|---|
| Emissions | Final Tier 4 (FT4)/Stage V | |||
| Number of cylinders | Four | |||
| Displacement | 4.5 L 275 cu in. |
|||
| Alternator | 120 amp | |||
| Fuel tank capacity | 340.7 L 90 gal. |
|||
| Diesel exhaust fluid (DEF) tank capacity | 21.6 L 5.7 gal. |
| Glass | 5.45 m2 58.7 sq ft |
|||
|---|---|---|---|---|
| Seat | Air suspension | |||
| Instructional seat | Standarded | |||
| Windshield wiper | Single blade |
| Toolbar outriggers | 12-row: 340.4 cm 134 in. |
|||
|---|---|---|---|---|
| Row configurations | 12 | |||
| Detasseling control system | Tasseltrol | |||
| Cutter height range | Lower lift position range: 55.4 to 222.5 cm 21.8 to 87.6 in. Upper lift position range: 75.1 to 242.2 cm 29.6 to 95.4 in. |
|||
| Puller height range | Lower lift position range: 46.2 to 213.3 cm 18.2 to 83.9 in. Upper lift position range: 65.9 to 233 cm 25.9 to 91.7 in. |
|||
| Quad Puller operating speed | Factory setpoint: 450 rpm | |||
| Cutter operating speed | Factory setpoint: 2800 rpm |
| Option 1 | Quad Puller - 12 Row 6 Lift Row spacing: 76.2 cm 30 in. |
|||
|---|---|---|---|---|
| Option 2 | Cutter - 12 Row 6 Lift Row spacing: 76.2 cm 30 in. |
|||
| Option 3 | ||||
| Option 4 | ||||
| Option 5 | ||||
| Option 6 | ||||
| Option 7 | ||||
| Option 8 | ||||
| Option 9 | ||||
| Option 10 |
| Type | Hydrostatic | |||
|---|---|---|---|---|
| Drive | Full-time four-wheel drive (4WD) | |||
| Shifting | Dual speed range | |||
| Hydraulic reservoir capacity | 65.3 L 17.25 gal. |
|||
| Detasseling speed range | Low range: 0 to 16.1 km/h 0 to 10 mph High range: 0 to 20.9 km/h 0 to 13 mph |
|||
| Transport speed, maximum | 20.9 km/h 13 mph |
| Dry compatible | No | |||
|---|---|---|---|---|
| Suspension | Independent air-ride | |||
| Crop clearance with standard tires | 195.6 cm 77 in. |
|||
| Front tires | Titan® 12.4 x 38 | |||
| Rear tires | Titan 12.4 x 38 | |||
| Flotation tires | ||||
| Hydraulic tread adjust | Manual only | |||
| Wheel tread spacing | 254 to 304.8 cm 100 to 120 in. |
|||
| Wheelbase | 307.3 cm 121 in. |
|||
| Turning radius | 5.5 m 18 ft |
|||
| Parking brake | Integrated in final drives | |||
| Primary brakes | Drive system dynamic braking | |||
| Ladder raise/lower | Fixed ladder | |||
| Approximate dry weight | Based off of a 12 row 6 lift machine with cutters: 6965.8 kg 15,357 lb |
| Date collected | 23-Aug-23 |
|---|
Images of equipment models may be digitally generated, are for illustration purposes only, and are subject to change. Equipment models shown are typically base models and may not reflect all features, options, or attachments. Equipment availability may be limited. See your John Deere dealer for additional information.
1Preproduction model shown. Specifications and design subject to change.
*Based off of a 12-row 6-lift machine with cutters.
